Voltage measurement range
|
M2174A : 10µV to 100Vrms/F.S.
M2177A : 30µV to 100Vrms/F.S.
|
|
Frequency range
|
5Hz to 500kHz
|
|
Input impedance
|
approx. 1M ohm 20pF max.
|
|
Max. inuput voltage
|
30mV to 100V range : AC ± DC peak value ± 250V
10µV to 10mV range : AC ± 5Vpeak, AC ± DC peak value ± 250V
|
Indication accuracy
(average reponse, reference to F.S.)
|
10µV range : 10Hz to 30kHz ± 10% (M2174A only)
30µV range : 10Hz to 30kHz ± 5%
100µV range : 10Hz to 100kHz ± 5%
300µV to 100V range : 5Hz to 500kHz ± 10%
|
|
AC output
|
1V (F.S., no load), output impedance : approx. 50Ω typ.
|
|
DC output
|
1V (F.S., no load), output impedance : approx. 50Ω typ.
|
|
Meter
|
Taut-band with mirror type
|
|
Weighting network
|
Built-in 4 types filter * :
JIS-A (JIS C 1502A), JIS-C (JIS C 1502C),DIN-45405 (AUDIO), CCIR-ARM
Possible to add another 2 filters as option
|
|
Power requirements
|
AC100V, 120V, 230V, switchable
|
|
Dimensions (mm)
|
140(W) X 177(H) X 300(D)
|
|
Weight
|
approx. 3.5kg
|
